How To Set Up an Elasticsearch, Fluentd and Kibana (EFK) Logging Stack on Kubernetes

We’ll begin by configuring and launching a scalable Elasticsearch cluster, and then create the Kibana Kubernetes Service and Deployment. To conclude, we’ll set up Fluentd as a DaemonSet so it runs on every Kubernetes worker node.

This tutorial looks at how to spin up a single node Elasticsearch cluster along with Kibana and Fluentd on Kubernetes.

Dependencies:

Docker v18.09.1 Kubernetes v1.13.2 Elasticsearch v6.5.4 Kibana v6.5.4 Fluentd v1.3.2

Prerequisites

Before you begin with this guide, ensure you have the following available to you:

A Kubernetes 1.10+ cluster with role-based access control (RBAC) enabled

Ensure your cluster has enough resources available to roll out the EFK stack, and if not scale your cluster by adding worker nodes. We’ll be deploying a 3-Pod Elasticsearch cluster (you can scale this down to 1 if necessary), as well as a single Kibana Pod. Every worker node will also run a Fluentd Pod. The cluster in this guide consists of 3 worker nodes and a managed control plane. The kubectl command-line tool installed on your local machine, configured to connect to your cluster. You can read more about installing kubectl in the official documentation. Once you have these components set up, you’re ready to begin with this guide.

Step 1: Set up a GKE Cluster on Gcloud

When launching a GKE cluster to run Portworx, you need to ensure that the cluster is based on Ubuntu. Due to certain restrictions with GKE clusters based on Container-Optimized OS (COS), Portworx requires Ubuntu as the base image for the GKE Nodes.

The following command configures a 3-node GKE Cluster in zone ap-south-1-a. You can modify the parameters accordingly.

Step 1 — Start configuration on cli

$ gcloud init

Create Cluster

$ gcloud container clusters create "gke-logging" \
--zone "asia-south1-a" \
--username "admin" \
--cluster-version "1.8.10-gke.0" \
--machine-type "n1-standard-1" \
--image-type "UBUNTU" \
--disk-type "pd-ssd" \
--disk-size "100" \
--num-nodes "3" \
--enable-cloud-logging \
--enable-cloud-monitoring \
--network "default" \
--addons HorizontalPodAutoscaling,HttpLoadBalancing,KubernetesDashboard

Start configuration on cli

$ gcloud container clusters get-credentials gke-logging --zone asia-south1-a  --project my-project

Verify configuration on cli

$ kubectl get nodes

Step 2 — Creating a Namespace

$ kubectl create namespace logging

Step 3 — Creating a storage class for ELK stack on GKE

$ kubectl create -f elastic-sc.yaml -n logging

Step 4 — Creating the Elasticsearch StatefulSet on GKE

$ kubectl create -f elastic-app.yaml -n logging

Verify the running pods

$ kubectl get pods -n logging

Verify the running service

$ kubectl get service -n logging

Port Forward for Check Elastic Test Connection Form the current cli

$ kubectl port-forward elasticsearch-0 9200:9200 -n logging & [1] 18200

And Check Kebana is access in browser

$ curl localhost:9200

Let’s get the count of the nodes.

$ curl -s localhost:9200/_nodes | jq ._nodes

Step 5 — Creating the Kibana Deployment and Service on GKE

$ kubectl create -f kibana-app.yaml -n logging

Verify the running pods

$ kubectl get pods -n logging

Verify the running service

$ kubectl get service -n logging

And Verify kibana

$ kubectl port-forward kibana-87b7b8cdd-7wm5d 5601:5601 -n logging

And Check Kebana is access in browser http://localhost:5601.

(Optional) Expose Elasticsearch service externally

$ kubectl patch svc "kibana" --namespace "logging" --patch '{"spec": {"type": "LoadBalancer"}}'

Get the Elasticsearch URL

$ SERVICE_IP=$(kubectl get svc "kibana" --namespace "logging"  --output jsonpath='{.status.loadBalancer.ingress[0].ip}')

And Than set Url

$  ELASTIC_URL="http://${SERVICE_IP}:5601"
